DERT Lighting
1 / 5
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Forward current | If | 350 | mA |
| Reverse Voltage | Vr | 5 | V |
| Power dissipation | Pd | 1 | W |
| Operating temperature | Top | -40 ~ +85 | °C |
| ESD (Human-body mode) | -- | 2 | KV |
| Storage temperature | Tstg | -40 ~ +85 | °C |
| Peak pulsing current (1/8 duty f=1kHz) | lfP | 700 | mA |
| Parameter | Test Condition | Symbol | Value | Unit | ||
|---|---|---|---|---|---|---|
| Min | Typ | Max | ||||
| Color temperature | If=350mA | CCT | 2000 | --- | 8000 | K |
| Forward voltage | If=350mA | Vf | 2.8 | --- | 3.4 | V |
| Luminous intensity | If=350mA | Iv | 120 | --- | 150 | LM |
| Viewing angle at 50% Iv | If=1500mA | 2θ1/2 | -- | 120 | -- | Deg |
| Reverse current | Vr=5V | Ir | -- | -- | 10 | μA |
Standard export carton packing.
1-7 days after confirming order. Detail delivery date should be decided according to production season and order quantity.
Established in 2004 with a 100,000-grade purification constant temperature and humidity anti-static production workshop, we mainly produce various LEDs, including PCB, bracket, and TOP type categories.
We deliver LEDs to renowned customers around the world. Supported by a team with 20 years of management experience in packaging enterprises, we have witnessed the rapid development of the LED industry, accumulated rich experience in LED R&D and packaging technology, and formed a scientific management system. Our monthly production exceeds 5,000KK pieces.
Our products are the result of experienced manufacturing processes, rigorous quality control, and carefully selected raw material supplies. Massive production meets high quality demands and competitive pricing within the LED industry.
We provide excellent sales service and strong technical supports to our customers.
12,000,000 pcs per day capability.
Multiple sets of testing equipment and SGS authorization.
Designed and produced based on customer requirements.
Team with over 20 years of production and management experience.
A: Your inquiry will be replied to within 24 hours. We offer dedicated protection of your sales area, design ideas, and private information. We guarantee consistent quality and service regardless of your order size, utilizing advanced ASM machinery, premium chips, and epoxy resin.
A: Customers can provide images or physical samples of the failed products. Our after-sales engineering team will analyze the cause of the issue. If the defect is caused by production, we will quickly compensate with qualified replacements.
A: Yes, we provide free samples to our customers for evaluation purposes.
A: It depends on your order quantity. Generally, the standard lead time is 5-7 working days. For standard samples, delivery can be arranged as fast as the same day.
A: Our monthly manufacturing output exceeds 5,000KK pieces, ensuring we can easily scale to meet large-volume demand.
A: Yes, we provide full OEM and ODM support, tailoring product specifications, shapes, and designs to meet customer requirements.
