📌 Widely Used In: Airport, station, catering industry, entertainment industry, medical institution, golf course, supermarket, exhibition, stadium and gymnasium, financial industry, organ and enterprise, building advertising and billboard advertising, subway, hotel, railway station, bus station, lift, bank, commercial center, wedding photograph, large exhibition, mobile show, chain-store, and more.
| Screen Configuration | Motherboard Configuration |
|---|---|
|
• Screen size: 32" • Resolution: 1920 (RGBW) × 1080 [UHD] • Display size: 698.4(W) × 392.85(H) mm • Visual size: 727.4(W) × 429(H) mm • Brightness (cd / m2): 400 (Typ.) • Best angle: full view • Viewing angle: 89/89/89/89 (Min.) (CR≥10) • Number of colors: 16.7M, 72% (CIE1931) • Point distance: 0.124x0.372mm • Screen Weight: 5.70Kgs (Typ./Max.) • Refresh frequency: 60Hz • Signal system: LVDS (2 ch, 8-bit), 51 pins, terminal • Supply voltage: 12.0V (Typ.) • Storage temp: -20 ~ 60 °C | Operating temp: 0 ~ 50 °C • Screen type: LCD module, a-Si TFT-LCD • Pixel configuration: RGBW vertical strip • Dimensions: 705.6(W) × 400.1(H) × 10.5(T) mm • Surface treatment: matte (Haze 1%), Hard coating (3H) • Contrast: 1000: 1 (Typ.) [Transmission] • Optical mode: TN, often black display, transmission type • Response speed: 7/5 (Typ.) (Tr / Td) ms • Backlight type: WLED, 50K hours, with LED driver |
• Built-in dual eight 24-bit LVDS, support 1920*1080 resolution, support dual screen display. • Onboard 2*Mini-PCIE, support WIFI, 3G & MSATA • Support 7*24H running around the clock. • 6COM and 2COM are optional. 6COM supports RS485/422, dual network 6COM version of industrial computer preferred. • Onboard HDMI interface, support 1920*1080 HD playback, onboard 5W amplifier, Spdif fiber • Standard LPT pin for on-board print port. • Dimensions: Mini-ITX frame, 170mm*170mm • Thickness: 18mm audio interface • Integrated Realtek ALC662 HD digital audio decoder • Supports Line-out, MIC-in interface, with front pin pins. • Onboard 5W amplifier, supporting Spdif fiber output • Processor: Core 3217U, 3317U, 3517U, dual core 1.7G or 1.8G or 1.9G. Low power consumption and fast operation. The processor integrates the display core and the memory controller. • I/O expansion: 7*USB, high speed USB 2.0 controller, 480Mbps rate. 2*RS232 COM, 6COM optional, RS485 optional. • Standard pin on the onboard print port. |
| Infrared Touch Parameters | |
|
• Material: Tempered glass • Glass thickness: 3mm, 4mm, 6mm • Surface abrasion strength: strong, determined by the glass surface • Transparency: ≥95%, up to 100% (no glass) • Homogeneity: Good |
|
| Touch Parameters | Electrical Parameters |
|
• Design life: more than 5 years • Touch fastest response speed: 6ms • Touch average reaction speed: 8ms |
• Working voltage: 4.5 ~ 5.5Vdc • Working current: ≤120mA • Power: ≤ 900mW |
Package: Standard export carton packing.
Delivery Time: 3-20 days after confirming order, detail delivery date should be decided according to production season and order quantity.
